ASUS ROG Strix B460-H Gaming B460 LGA 1200 (Intel 10ª generación) ATX Gaming Motherboard (Intel 1Gb LAN, USB 3.2 Gen 2, Thunderbolt 3 Header, Direccionable Gen2 RGB Header y Aura Sync)
Código: 3186
Marca ASUS
Zócalo de CPU LGA 1200
Tecnología de memoria RAM DDR4
Tipo de set de chips Intel B460
Velocidad de memoria 2933 MHz
Plataforma Windows 10
Series ROG STRIX B460-H GAMING
Capacidad de almacenamiento de memoria 128 GB
Memoria RAM capacidad máxima 128 GB
Tipo de conector de alimentación principal 24-pin
Intel LGA 1200 Socket: diseñado para dar rienda suelta al máximo rendimiento de los procesadores Intel Core de 10ª generación
Diseño térmico optimizado: disipador de calor VRM, disipador de calor PCH sin ventilador, disipador de calor M. 2, cabezales de ventilador híbridos y utilidad Fan Xpert 4
Audio para juegos líder en la industria: audio de alta fidelidad con el códec SupremeFX S1220A, DTS Sound Unbound y Sonic Studio III te atrae más profundamente en la acción del juego
Personalización inigualable: aspecto de juego rojo sobre negro, iluminación RGB Aura Sync exclusiva de ASUS, incluyendo encabezados RGB RGB y cabeceras direccionables Gen 2
Red de juegos de alto rendimiento: Intel 1 GB LAN con ASUS LANGuard
Conectividad más rápida: compatible con HDMI 1. 4 y DisplayPort 1. 4 salidas, y con doble M. 2, cabezal Thunderbolt 3
Solución de alimentación robusta: 6 + 1 + 1 Dr. MOS etapas de potencia con conector de alimentación ProCool, estranguladores de aleación de alta calidad y condensadores duraderos para proporcionar energía fiable al empujar el rendimiento de la CPU al límite
ekipos.com
-
CPU
Intel® Socket 1200for 10th Gen Intel® Core™, Pentium® Gold and Celeron® Processors
Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0**
**Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types.
Supports Intel® 14nm CPU
* Refer to www.asus.com for CPU support list
Chipset
Intel® B460
Memory
4 x DIMM, Max. 128GB, DDR4 2933/2800/2666/2400/2133 MHz Non-ECC, Un-buffered Memory *
OptiMem
* 10th Gen Intel® Core™i9/i7 CPUs support 2933/2800/2666/2400/2133 natively, Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
Dual Channel Memory Architecture
Supports Intel® Extreme Memory Profile (XMP)
Graphic
1 x DisplayPort 1.4 **
**Support DisplayPort 1.4 with max. resolution of 4096 x 2304 @60Hz. Please refer to www.intel.com for any update.
1 x HDMI 1.4b
*Graphics specifications may vary between CPU types.
Integrated Graphics Processor
Multi-GPU Support
Supports AMD 2-Way CrossFireX Technology
Expansion Slots
Intel® B460 Chipset
3 x PCIe 3.0 x1 *2
Intel® 10th Gen Processors
1 x PCIe 3.0 x16 (x4 mode) *1
1 x PCIe 3.0 x16
Storage
1 x M.2_1 socket 3, with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)*3
Intel® B460 Chipset :
Total supports 2 x M.2 slots and 6 x SATA 6Gb/s ports
1 x M.2_2 socket 3, with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode)
6 x SATA 6Gb/s port(s)
Support Raid 0, 1, 5, 10
Intel® Optane™ Memory Ready
LAN
Intel® I219-V 1Gb Ethernet
ASUS LANGuard
Wireless Data Network
M.2 slot only (Key E) (Support PCIe interface)*
*Wi-Fi module is sold separately.
Audio
ROG SupremeFX7.1 Surround Sound High Definition Audio CODEC
- Rear audio USB Type-C® port
- Premium Japanese audio capacitors
- Audio Cover
- Dual OP Amplifiers
- Impedance sense for front and rear headphone outputs
- Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking
- High quality120dBSNR stereo playback outputand113dBSNR recording input
- Supports up to 32-Bit/192kHz playback
Audio Feature :
- SupremeFX Shielding™ Technology
* Due to limitations in HDA bandwidth, 32-Bit/192kHz is not supported for 8-Channel audio.
USB Ports
Rear USB Port ( Total 7 )
Front USB Port ( Total 6 )
6 x USB 3.2 Gen 1 port(s)(6 x Type-A)
1 x USB 3.2 Gen 2x2 port(s)(1 x USB Type-C®)
2 x USB 3.2 Gen 1 port(s)
4 x USB 2.0 port(s)
Software Features
[ROG Exclusive Software]
- RAMCache III
- ROG CPU-Z
- GameFirst VI
- Sonic Studio III + Sonic Studio Virtual Mixer
- Sonic Radar III
- DTS® Sound Unbound
- Overwolf
- Anti-virus software
[ASUS Exclusive Software]
Armoury Crate
- Aura Creator
- Aura Sync
AI Suite 3
- Performance And Power Saving Utility: TurboV EVO, EPU, Digi+ VRM, Fan Xpert 4
- EZ update
ASUS CPU-Z
DAEMON Tools
WinRAR
[UEFI BIOS]
ASUS EZ DIY
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 3
- ASUS UEFI BIOS EZ Mode
ASUS Special Features
Extreme Engine Digi+
- 5K Black Metallic Capacitors
ASUS Q-Design
- ASUS Q-DIMM
- ASUS Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green])
- ASUS Q-Slot
ASUS Thermal Solution
- Aluminum M.2 heatsink
ASUS EZ DIY
- BIOS FlashBack™ button
- BIOS FlashBack™ LED
- Procool
- Pre-mounted I/O shield
- SafeSlot
AURA Sync
- Standard RGB header(s)
- Addressable Gen 2 RGB header(s)
Rear audio USB Type-C® connector
Back I/O Ports
1 x Intel® I219-V 1Gb Ethernet
1 x USB 3.2 Gen 2x2 port(s) (1 x USB Type-C®)
6 x USB 3.2 Gen 1
1 x DisplayPort
1 x HDMI
1 x Optical S/PDIF out
5 x Audio jack(s)
Internal I/O Ports
1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen 1 port(s)
1 x Aura RGB Strip Headers
2 x M.2 Socket 3
1 x Thunderbolt header(s)
1 x CPU Fan connector(s)
1 x CPU OPT Fan connector(s)
2 x Chassis Fan connector(s)
1 x AIO_PUMP connector
1 x AAFP connector
1 x Addressable Gen 2 header(s)
2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
1 x M.2 with E key for Wi-Fi module
6 x SATA 6Gb/s connector(s)
1 x 24-pin EATX Power connector(s)
1 x 8-pin ATX 12V Power connector(s)
1 x System panel connector
Accessories
1 xM.2 Key E screw package(s)
1 x M.2 SSD screw package(s)
1 x M.2 Rubber Package(s)
1 x pack of cable tie
User´s manual
4 x SATA 6Gb/s cable(s)
1 x Supporting DVD
1 x ROG Strix stickers
1 x Extension cable for Addressable LED
1 x ROG Thank you card
BIOS
128 Mb Flash ROM, UEFI AMI BIOS
Manageability
WOL by PME, PXE
Operating System
Windows® 10 64-bit
Form Factor
ATX Form Factor
12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
-
