Tenda D301v2 Broadband CPE Wireless N300 ADSL2+ Modem Router

TENDA D301v2 CPE de banda ancha Router-módem N300 ADSL2+ inalámbrico
Código: 2640 | Garantía:12 meses | Peso:kg. 1.00

Producto Agotado

No disponible, descontinuado.

Ingrese para ver precios

Tenda D301v2 Broadband CPE Wireless N300 ADSL2+ Modem Router

111114 8048 Compartir

+ Tenda | Similares (57) | Redes de datos | Ultimos

« Anterior Producto Siguiente »

Routers | Tenda D301v2 Broadband CPE Wireless N300 ADSL2+ Modem Router | Ekipos | 72044155
TENDA D301v2 CPE de banda ancha Router-módem N300 ADSL2+ inalámbrico
The D301 is a true one-stop solution, serving as a wired and wireless modem and router. It combines all the functionality of ADSL 2/2+ modem, WiFi router, and 4-port switch, and adds to it with a range of features, including USB sharing, IPTV, easy setup, and TR069.
Standard&Protocol
IEEE802.11b/g/n
IEEE 802.3, 802.3u
G.994 compliant
Full-rate ANSI T1.413 Issue 2
ITU-T G.992.1 (G.dmt)
ITU-T G.992.2 (G.lite)
ITU-T G.992.3 (G.dmt.bis) Annex A/L/M
ITU-T G.992.5 Annex A
Interface
RJ11 × 1
Power Jack × 1
USB2.0 × 1
10/100Mbps LAN × 3
10/100Mbps WAN/LAN × 1
Antenna
5dBi External Omni directional × 2
Button
Reset(RST) × 1
WPS × 1
WLAN On/Off × 1
Power On/Off × 1
Power
Input: 100 - 240V 50/60Hz
Output: 9V1.0A
Dimension
157.8 × 105.2 × 29.4mm
LED indicator
PWR, SYS, INTERNET, USB, WPS, WLAN, 4/iTV, LAN3, LAN2, 1/WAN, DSL
Wireless Rate
300Mbps
Frequency
2.4GHz
RF Power
<20dBm(EIRP)
Basic Features
Wireless switch enable/disable
SSID Broadcast enable/disable
Country Options
Channel: Auto, 1-13
Bandwidth: Auto, 20MHz, 40MHz
Client List
WDS
Wireless Security
Wireless MAC Filtering
Support 64/128 bit WEP
WPA-PSK/WPA2-PSK
WPS
Connection Type
PPPoE, PPPoA,IPoA, MER, Bridge
Operating Mode
Wireless Modem Router, Wireless Router
Advanced Functions
PVC Configuration
MAC Clone
DSL Settings
Interface Grouping
QoS
USB Sharing(Samba)
Parental Control
IPTV
USB Sharing
Storage Sharing( Samba)
DHCP
DHCP Server
Client List
Address Reservation
Virtual Server
Port Forwarding
Port Triggering
DMZ
UPnP
Security
IP Filter
MAC Filtering
IPv6
Support 6RD & DS-Lite, IPv6 and IPv4 dual stack
Management
LAN IP Setting
Backup & Update & Restore to factory default
System Logs
SNMP Agent
TR-069 Client
Internet Time
Access Control
Update Software via web, TFTP & FTP
Diagnostics
DDNS, IGMP Multicast, VLAN, 802.1Q, Routing
Temperature
Operating Temperature: 0? ~ 40?
Storage Temperature: -40ºC~70ºC
Humidity
Operating Humidity: 10% ~ 90%RH non-condensing
Storage Humidity: 5% ~ 90%RH non-condensing
Default Settings
IP Address: 192.168.1.1
Login Username?admin Login Password: admin
Certification
CE?FCC?RoHS
Package Content
300Mbps Wireless N ADSL2+ Modem Router × 1
Quick Installation Guide x 1
Power Adapter x 1
Ethernet cable (RJ45) x 1
Telephone cable ( RJ11) × 2
Splitter x 1
